TP208s Top Speaker

Description

Introducing the TP208s a dual 8″ coaxial Mid/Hi speaker cabinet designed to complement our range of subwoofer cabinets.

All DS Sound speaker cabinets are CNC machined in our own factory to ensure a high quality fit and finish and are constructed from high quality waterproof birch plywood. After the cabinet is constructed and hand finished it is sprayed with a tough polyurethane 2 component coating to further protect it from the elements.

All cabinets use the highest quality Italian transducers complemented by our own passive filter networks assembled using only the best grade passive components. (Subwoofers are actively filtered via our DSP amplifiers or external loudspeaker management)

Optional bracketry/mounts and custom RAL finishes can be specified during the consultation phase.

Technical Specifications:

• Height: 285mm (11.22″)

• Width: 580mm (22.83″)

• Depth: 166mm – 295mm (6.54″ – 11.61″)

• Weight: 16kg

• Power: 500 Watt RMS

• Sensitivity (1W@1m): 97 dB

• Max SPL: 126 dB

• Frequency response (-3dB): 75Hz – 18KHz

• Configuration: 2 x 8” coaxial with centre mounted dual 1″ HF

Features:

• Waterproof birch plywood cabinet finished with tough polyurethane waterproof coating

• Galvanized polyurethane coated steel grille

• Stainless steel screws

• Tough ABS recessed panel for twin Speakon connections.
